SNP200-12VL

LED POWER SUPPLY DATASHEET SNP200-12VL ·DESCRIPTION High Cost Performance, SELV. Short circuit, open circuit, overload and over temperature protection.Compliance to ERP directive, lifetime 30,000hrs. ·Input ·Output Items Conditions Rated Input voltage Request Note Items Conditions Request Note <0.5S -- 12V±5% -- 25℃, rated input voltage, output with max. rated power 200-240Vac ...
развернуть ▼ свернуть ▲

Технические характеристики

показать свернуть
Тип преобразователя
Мощность выходная
Диапазон выходных напряжений
Диапазон выходных токов
Напряжение сети/входное номинальное
Режим стабилизации
Тип диммирования
Исполнение конструктивное
Степень защиты (IP)
Подстройка выходных параметров
Диапазон входных напряжений (AC)
Напряжение изоляции вход-выход
Количество выходов
Коэффициент мощности
Функция защиты
Температура рабочая
Размер 195×67.1×31.2 мм
Применение
Нашли ошибку? Выделите её курсором и нажмите CTRL + ENTER

Файлы 1

показать свернуть
LED POWER SUPPLY DATASHEET SNP200-12VL ·DESCRIPTION High Cost Performance, SELV. Short circuit, open circuit, overload and over temperature protection.Compliance to ERP directive, lifetime 30,000hrs. ·Input ·Output Items Conditions Rated Input voltage Request Note Items Conditions Request Note <0.5S -- 12V±5% -- 25℃, rated input voltage, output with max. rated power 200-240Vac -- Startup time Input frequency 50/60Hz -- Ta, rated input voltage, Output voltage and precision output with rated power Input current < 1.5A -- Output current range Ta ,rated input voltage 0-15A -- < 200W -- Output voltage wave 25℃, rated input voltage, output with max. rated power 300mV Vp-p ≥ 92 % -- Output overload 25℃, rated input voltage, output with 2 times LED load Yes -- <0.21W average Ta, rated input voltage, Output current and precision output with rated power -- -- Rated output voltage range Ta, rated input voltage -- -- -- Ip-p Ta Input power 25℃, rated input voltage, output with max. rated power Effiency Standby 25℃, rated input voltage, output without load Inrush current 25℃, rated input voltage <75A peak PF 25℃, rated input voltage, output max. rated power ≥ 0.9 -- ·Temperate and others Items Conditions Request Note Operation temp. -- -20-45℃ -- Relative humidity -- 45%-85% -- Max. case temp. -- 80℃ -- Max.Ta,rated input voltage,output with max.rated power 30,000hr -- 25℃, rated input voltage, output with rated power, mute box background noise<35dB, pickup 10cm distance from products Yes Lifetime Working noise Dimming mode -- -- -- Dimming range -- -- -- ·Mechanical, mounting Items Case material and size Conditions Note -- -- Yes -- Ta, 0.94-1.06 times of input voltage Yes -- Over temperature Ta, 0.94-1.06 times of input voltage, temperature detected pointed more than 115 degree Yes -- Over voltage Ta, 0.94-1.06 times of input voltage,output voltage is 1.5 times of rated one Yes Auto recovery Over load, short circuit revocation Latch off Over voltage, over temperature re-start after cut off Over load Ta, 0.94-1.06 times of input voltage, 1.2 times of rated power Short circuit Plastic L195*W67.1*H31.2mm Independent Insulation type Class II IP grade Request Ta, rated input voltage, no load Conditions Mounting ways IP20 Input cables dimension H05VVH2-F 1.0mm² Output cables dimension H05VVH2-F 1.0mm² Output cables length Open circuit 25℃, rated input voltage, output with max. rated power -- ·Protection Item Output current wave Max 2m ·Standard Items Conditions Safety IEC61347-1、IEC61347-2-13 -- Harmonic EN61000-3-2 Class C Yes -- EMI EN55015 Yes -- EMS EN61000-4-2、3、4、5、6 EN61547 PDF
Документация на SNP200-12VL

Subject:

Дата модификации: 27.11.2019

Размер: 224.8 Кб

2 стр.
