APHBM2012SURKCGKC

Kingbright
APHBM2012SURKCGKC 2.0 x 1.25 mm SMD Chip LED Lamp DESCRIPTIONS      PACKAGE DIMENSIONS The Hyper Red source color devices are made with AlGaInP on GaAs substrate Light Emitting Diode The Green source color devices are made with AlGaInP on GaAs substrate Light Emitting Diode Electrostatic discharge and power surge could damage the LEDs It is recommended to use a wrist band or anti-ele...
развернуть ▼ свернуть ▲


Технические характеристики

показать свернуть
Цвета свечения
Количество цветов в корпусе
Длина волны 1 цвета 570
Длина волны 2 цвета 630
Сила света 1 кристалла
Сила света 2 кристалла
Угол по горизонтали
Тип линзы
Схема включения
Размер 2×0.45 мм
Рабочая температура
Примечания Dual Color LED, Hyper Red/green, Water Clear, 1.3mm
Нашли ошибку? Выделите её курсором и нажмите CTRL + ENTER

Аналоги 2

показать свернуть
Тип Наименование Корпус Упаковка i Цвет N λ1 Длина волны 2 λ3 Iv1 Iv2 Iv3 Tц Поток U Pик αX αY CIE x CIE y Корпус Линза Схема T раб Примечания Карточка
товара
P= KPHBM-2012SURKCGKC (KGB)

SMD4 в ленте 2000 шт 630 570 — — — — — — — — — — — Dual Color LED, Hyper Red/green, Water Clear, 1.3mm
P- FYLS-0805URUGC (FORYARD)

— в ленте 12000 шт

 — — — — — — — — — — — — — — — — — — — —

Файлы 1

показать свернуть
APHBM2012SURKCGKC 2.0 x 1.25 mm SMD Chip LED Lamp DESCRIPTIONS      PACKAGE DIMENSIONS The Hyper Red source color devices are made with AlGaInP on GaAs substrate Light Emitting Diode The Green source color devices are made with AlGaInP on GaAs substrate Light Emitting Diode Electrostatic discharge and power surge could damage the LEDs It is recommended to use a wrist band or anti-electrostatic glove when handling the LEDs All devices, equipments and machineries must be electrically grounded FEATURES         2.0 mm x 1.25 mm SMD LED, 0.45 mm max. thickness Low power consumption Wide viewing angle Ideal for backlight and indicator Package: 2000 pcs / reel Moisture sensitivity level: 3 Halogen-free RoHS compliant RECOMMENDED SOLDERING PATTERN APPLICATIONS      (units : mm; tolerance : ± 0.1) Backlight Status indicator Home and smart appliances Wearable and portable devices Healthcare applications ATTENTION Observe precautions for handling electrostatic discharge sensitive devices Notes: 1. All dimensions are in millimeters (inches). 2. Tolerance is ±0.1(0.004") unless otherwise noted. 3. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice. 4. The device has a single mounting surface. The device must be mounted according to the specifications. SELECTION GUIDE Part Number Emitting Color (Material) Iv (mcd) @ 20mA [2] Viewing Angle [1] Lens Type Min. Typ. 120 250 *40 *80 20 50 *20 *50 2θ1/2 ■ Hyper Red (AlGaInP) APHBM2012SURKCGKC 120° Water Clear ■ Green (AlGaInP) Notes: 1. θ1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value. 2. Luminous intensity / luminous flux: +/-15%. * Luminous intensity value is traceable to CIE127-2007 standards. © 2020 Kingbright. All Rights Reserved. Spec No: DSAG7623 / 1203005979 Rev No: V.16A Date: 05/04/2020 Page 1 / 4 PDF
Документация на APHBM2012SURKCGKC

APHBM2012SURKCGKC(Ver.16A)

Дата модификации: 04.05.2020

Размер: 561.9 Кб

4 стр.

    Внимание! Точность указанного на сайте описания товара не может быть гарантирована. Для получения более полной и точной информации о товаре смотрите техническое описание (Datasheet) на сайте производителя.
