Серия DC-DC модульных преобразователей PV_29B

Mornsun

Общие характеристики

	Раздел	DC-DC модульные преобразователи
	Количество каналов
	Входное напряжение
	Возможности
	Комплекс защит
	Номинальное входное напряжение
	КПД
	Напряжение изоляции вход-выход
	Рабочая температура

Документация на серию PV_29B

DC/DC Converter PV15(40)-29Bxx Series 10-40W isolated DC-DC converter with ultra-wide, ultra-high 200 - 1500V DC input for renewable energy FEATURES  Ultra wide input voltage range: 200 - 1500VDC  Industrial grade operating temperature: -40℃ to     Report CSA-C22.2 No.107.1-16 UL1741  RoHS +70℃ 4000VAC high isolation voltage High efficiency, low ripple & noise Input under-voltage protection, input reverse polarity protection, output short circuit, over-current, over-voltage protection Mounting: PCB mounting, DIN-Rail mounting available Reinforced insulation EN62109-1 PV15(40)-29Bxx series is regulated DC-DC converters with an ultra-wide DC input of 200-1500VDC. The products feature high efficiency, high reliability, high insulation and high level of safety. This type of power supply is widely used in renewable energy industries such as photovoltaic, power generation, energy storage, inverters and high-voltage DC conversions. The converters provide multiple protection features and guarantee stable and safe operating environments even under abnormal working conditions. For extremely harsh EMC environment, we recommend using the application circuit show in Design Reference of this datasheet. Selection Guide Certification CSA/EN CSA/UL/EN Part No.* Output Power Nominal Output Voltage and Current (Vo/Io) Efficiency at 800VDC (%) Typ. Capacitive Load (µF) Max. (Normal temperature full load) PV15-29B05 10W 5V/2000mA 64 6000 12V/1250mA 71 2000 PV15-29B12 PV15-29B15 15V/1000mA 72 1200 PV15-29B24 15W 24V/625mA 74 470 PV40-29B12 12V/3330mA 78 3000 15V/2670mA 82 1500 24V/1670mA 83 680 PV40-29B15 40W PV40-29B24 Note: * Use suffix “A8” and “A10” for DIN-Rail mounting; A8 versions include built-in high-voltage fuse and EMC filter module, A10 only for DIN-rail; PV40 (“A8” and “A10” ) versions with UL/CSA/CE approved, PV15 (“A8” and “A10”) versions with CSA/CE approved. Input Specifications Item Operating Conditions Input Voltage Range 200VDC Input Current 800VDC 1500VDC Inrush Current Typ. Max. Unit VDC 200 -- 1500 PV15 -- -- 120 PV40 -- -- 320 PV15 -- -- 30 PV40 -- -- 80 PV15 -- -- 16 PV40 -- -- 42 200VDC -- 50 -- 1500VDC -- 150 -- mA A Lockout activation range: 170 - 185V Lockout deactivation range: 180 - 195V Under-voltage Protection External Input Fuse Required (A8 suffix versions with fuse included) Hot Plug Min. 4A/1500VDC, required Unavailable 2021.12.20-B/2 Page 1 of 6 MORNSUN Guangzhou Science & Technology Co., Ltd. reserves the copyright and right of final interpretation

Документация на PV40-29B24

PV15(40)-29Bxx Keywords:

Дата модификации: 13.01.2022

Размер: 1.79 Мб

6 стр.

DC/DC Converter PVxx-29Bxx Series New energy 200 - 1500VDC over wide and over high input voltage isolation converter FEATURES  Ultra wide input voltage range: 200 - 1500VDC  Industrial grade operating temperature: -40℃ to      RoHS +70℃ 4000VAC high isolation voltage High efficiency, Low ripple & noise Input under-voltage protection, reverse input voltage protection, Output short circuit, over-current, over-voltage protection Meets UL 1741, CSA-C22.2 No.107.1, EN6210 standards（Pending） Mounting: PCB mounting, DIN-Rail mounting available PVxx-29Bxx series -----is 200-1500VDC ultra wide input voltage regulated DC-DC converter, which has advantages such as high efficiency, high reliability and high safety isolation. The series products are widely used in industries such as photovoltaic power generation and high voltage frequency conversion, provide a stable operating voltage for the load device, Its multiple protection features can enhance the safety performance of the module power supply and the load under abnormal working conditions. For harsh EMC environment, this series of product must use the refered application circuit. Selection Guide Certification CSA/CE （Pending） UL/CSA/CE （Pending） Part No.* Output Power Nominal Output Voltage and Current(Vo/Io) Efficiency (800VDC, %/Typ.) Max. Capacitive Load(µF) (Normal temperature full load) PV15-29B05 10W 5V/2000mA 64 6000 12V/1250mA 71 2000 15V/1000mA 72 1200 PV15-29B24 24V/625mA 74 470 PV40-29B12 12V/3330mA 78 3000 15V/2670mA 82 1500 24V/1670mA 83 680 PV15-29B12 PV15-29B15 15W PV40-29B15 40W PV40-29B24 Note:*Part No. with suffix of “A8””A10” means DIN-Rail mounting (e.g.PV15-29B05A8/ PV15-29B05A10 means DIN-Rail mounting; A8 DIN-Rail package products built-in high-voltage fuse and EMC filter module, meets UL/CSA/CE standards (Pending) (PV40*A8); meets CSA/CE standards (Pending) (PV15*A8); A10 DIN-Rail package products have no high-voltage fuse and EMC filter module, meets UL/CSA/CE standards (Pending) (PV40*A10); meets CSA/CE standards (Pending) (PV15*A10). Input Specifications Item Operating Conditions Min. Typ. Max. Unit 200 -- 1500 VDC PV15 -- -- 120 PV40 -- -- 320 PV15 -- -- 30 PV40 -- -- 80 PV15 -- -- 16 PV40 -- -- 42 Input Voltage Range 200VDC Input current 800VDC 1500VDC Inrush current -- 50 -- 1500VDC -- 150 -- A Under voltage protection range: 170 - 185V Under voltage release range: 180 - 195V Under-voltage protection External input fuse (A8 Special package series include fuse) Hot Plug 200VDC mA 15A/1500VDC, necessary Unavailable 2018.05.23-A/6 Page 1 of 6 MORNSUN Guangzhou Science & Technology Co., Ltd. reserves the copyright and right of final interpretation

Документация на серию PV_29B

New energy 200 - 1500VDC over wide and over high

Дата модификации: 23.05.2018

Размер: 2.8 Мб

6 стр.

найти PV_29B.pdf

Товары серии PV_29B

Наименование	i	Упаковка	Монтаж	P вых	Выход	U1	I1	Размер
PV15-29B05 (MORNSUN)								125×75×40 мм
PV15-29B05A10 (MORNSUN)								146×138×55 мм
PV15-29B05A8 (MORNSUN)								129×102×49 мм
PV15-29B05L (MORNSUN)								109×58.5×30 мм
PV15-29B12 (MORNSUN)								125×75×40 мм
PV15-29B12A10 (MORNSUN)								146×138×55 мм
PV15-29B12A8 (MORNSUN)								129×102×49 мм
PV15-29B12L (MORNSUN)								109×58.5×30 мм
PV15-29B15 (MORNSUN)								125×75×40 мм
PV15-29B15A10 (MORNSUN)								146×138×55 мм
PV15-29B15A8 (MORNSUN)								146×138×55 мм
PV15-29B15L (MORNSUN)								109×58.5×30 мм
PV15-29B24 (MORNSUN)								125×75×40 мм
PV15-29B24A10 (MORNSUN)								129×102×49 мм
PV15-29B24L (MORNSUN)		1 шт						109×58.5×30 мм
PV40-29B12 (MORNSUN)								70×48×23.5 мм
PV40-29B12A10 (MORNSUN)								96.1×54×32 мм
PV40-29B12A8 (MORNSUN)								99×54×32 мм
PV40-29B15 (MORNSUN)								70×48×23.5 мм
PV40-29B15A10 (MORNSUN)								96.1×54×32 мм
PV40-29B15A8 (MORNSUN)								99×54×32 мм
PV40-29B17A7 (MORNSUN)			—			—	—	—
PV40-29B24 (MORNSUN)		2 шт						70×48×23.5 мм
PV40-29B24A10 (MORNSUN)								96.1×54×32 мм
PV40-29B24A8 (MORNSUN)		1 шт						99×54×32 мм
